LDPE High Speed Mono Layer Blown Film Machine
Features
- Application: T-shirt bag, packaging bag, construction film, agriculture film, lamination film etc.
- Suitable material: LDPE / LDPE+LLDPE
- Film layer: 1 layer
- Screw L/D ratio: 30:1
- Direct-connection design gearbox.
- PID+SCR temperature controller.
- ABB or HITACHI inverter.
| Items/Models | L25/300 | L35/500 | L45/800 | L55/1100 | L65/1500 | L80/2000 | L100/2500 | L120/3000 | L150/3500 | L180/4000 |
|---|---|---|---|---|---|---|---|---|---|---|
| Screw Diameter (mm) | 25 | 35 | 45 | 55 | 65 | 80 | 100 | 120 | 150 | 180 |
| Film Width (mm) | 50-200 | 150-400 | 400-700 | 600-1000 | 800-1350 | 1200-1800 | 1500-2300 | 2000-2800 | 2500-3300 | 3000-3800 |
| Output (kg/hr) | 6-12 | 15-28 | 25-50 | 40-80 | 60-120 | 120 - 180 | 180 - 280 | 240 - 360 | 350 - 500 | 450 - 750 |
| Film Thickness (mm) | 0.02-0.15, depending on the material & film size | |||||||||
| Main Motor (HP) | 5 | 10 | 20 | 30 | 50 | 75 | 100 | 150 | 200 | 300 |
| Items/Models | L25/300 | L35/500 | L45/800 | L55/1100 | L65/1500 | L80/2000 | L100/2500 | L120/3000 | L150/3500 | L180/4000 |
|---|---|---|---|---|---|---|---|---|---|---|
| Screw Diameter (mm) | 25 | 35 | 45 | 55 | 65 | 80 | 100 | 120 | 150 | 180 |
| Film Width (mm) | 50-200 | 150-400 | 400-700 | 600-1000 | 800-1350 | 1200-1800 | 1500-2300 | 2000-2800 | 2500-3300 | 3000-3800 |
| Output (kg/hr) | 6-12 | 15-28 | 25-50 | 40-80 | 60-120 | 120 - 180 | 180 - 280 | 240 - 360 | 350 - 500 | 450 - 750 |
| Film Thickness (mm) | 0.02-0.15, depending on the material & film size | |||||||||
| Main Motor (HP) | 5 | 10 | 20 | 30 | 50 | 75 | 100 | 150 | 200 | 300 |
